BY-100CA /BY-600H Automatic Combine Welding Positioner
Automated Combine Welding Positioner enable precision circular seam welding/cutting with pneumatic gun feeders & core clampers. Ideal for TIG welding, aerospace, automotive, and high-precision manufacturing workflows.
Table of Contents
Description
These type of Automatic Combine Welding Positioners can conduct automatic circular seam welding or cutting by being equipped with pneumatic welding or cutting gun feeding mechanism and pneumatic core clamper;
With a screw installed on an upright post , the distance between pneumatic core clamper and operation platform can be adjusted by turning the handle wheel .
The welding or cutting gun feeding mechanism is adjustable at any angles.
Specification
| Model | BY-100CA | BY-600H |
| Power Input | AC110V/220V 50/60HZ | AC220V 50Hz |
| Capacity(horizontal/vertical) | 100Kg/50Kg | 600Kg/300Kg |
| Table Dimension | 345mm | 450mm |
| Table Height | 415mm | 675mm |
| Rotation Speed | 1-7rpm or 2-15rpm | 0.2-1.8rpm |
| Tilt Range | 0-90° | 0-90° |
| Tilt Mode | Manual Drive | Motor Drive |
| Rotation Motor | 120W | AC0.37Kw |
| Tilt Speed | // | 2.5rpm |
