CR2800 Heavy Duty Two Stage Gas Regulator
CR2801 is a double-stage regulator suitable for those who have special requests. The structure of the two stages ensures stable pressure and flow.
Designed by internationally recognized standards EN ISO, BSP, CGA, NFE, and AS. Manufactured under ISO 9001.Conforms to ISO 2503.
Table of Contents
Description
DEM Two Stage Cylinder Regulators’ exceptional build quality and reliability.
The double-stage gas regulator keeps the working pressure constant until the cylinder empties.
1.Body: Forged brass
2.Bonnet: Forged brass and powder
3.Pressure Gauge: Safety design, 50mm gauge.
4.Inlet Stem & Nuts: High-tensile brass
5.Setting: PA Knob
6.Filter: Bronze
7.Weight: 1.45 kg/each
*Inlet thread type and inlet direction are subject to cylinder connection. The outlet thread type is subject to the buyer’s request.
Specification
| Part No. | Gas | Flow(M3/h) | Max Inlet Pressure(Bar) | Working Pressure (Bar) | Tolerance(Bar) |
| CR2801-OX | OXYGEN | 30 | 250 | 0.1-10 | ±0.1 |
| CR2801-AC | ACETYLENE | 5 | 30 | 0.1-1 | ±0.05 |
| CR2801-N | NITROGEN | 30 | 250 | 0.1-10 | ±0.1 |
| CR2801-CO2 | CO2 | 30 | 250 | 0.1-10 | ±0.1 |
| CR2801-HE | HEILUM | 30 | 250 | 0.1-10 | ±0.1 |
*1MPa=1000KPa=10.197kgf/cm2=145.04PSI 1M3/h=16.67LPM=35.32SCFH
Download
Q&A
Q: How do I know my regulator connection?
A: For the gas regulator, there are outlet and inlet connections. You can confirm the right connection size with your gas supplier.
Q: What is the maximum safe regulator pressure for oxygen use?
A: Depending on the size of the gas tank（oxygen cylinder) subsequent capacity may differ, but typically full pressure is about 2,000 psi and air pressure can go up to 3,000 psi. With the pressure in the tank, the Oxygen gas regulator reduces the supplied pressure to a lower, safer level for the user.
Q: Could I order according to my country’s standards?
A: DEM regulator design according to internationally recognized standards EN ISO, BSP, CGA, NFE, and AS. They are manufactured under the quality management of EN ISO 9001. DEM could offer the right type with the customer’s country standard.
Q: Could I use my brand and sticker?
A: DEM accepts OEM and ODM orders.
