WG026 Bridge Cam Fillet Gauge
Measurements up to 2″(50mm)
Angle of preparation
excess weld metal
Depth of undercut
Depth of ptiiing
fillet weld throat size
fillet weld length
outside misalignment
Table of Contents
Description
Pocket-size bridge cam fillet gauge
In both inches and millimeters:
– Angle of Preparation
– Excess Weld Metal
– Depth of Undercut
– Depth of Pitting
– Weld Throat Size and more.
Specification
|
Fillet leg length
|
0-20mm(0-3/4″)
|
|
Bevel angle
|
0-60 Deg
|
|
Fillet throat
|
0-10mm(0-1/2″)
|
|
Undercut/pitting depth
|
0-2mm(0-1/8″)
|
|
Misalignment
|
0-20mm(0-3/4″)
|
|
Material
|
Stainless steel
|
